Features & Benefits
Specifications
Unit | Width | Length |
---|---|---|
Roll | 18 in. | 100 ft. |
Roll | 3 ft. | 100 ft. |
Roll | 5 ft. | 200 ft. |
Roll | 9 ft. | 100 ft. |
Roll | 9 ft. | 150 ft. |
Roll | 9.50 ft. | 100 ft. |
Roll | 10 ft. | 100 ft. |
Roll | 10 ft. | 150 ft. |
<b>Tyvek® HomeWrap™</b> exhibits the properties and characteristics indicated in the table below when tested as represented. Review all instructions and (Material) Safety Data Sheet ((M)SDS) before use. Please contact your local DuPont™ Tyvek Specialist before writing specifications around this product. Product properties are as follows:
TEST METHOD | TEST TITLE | PROPERTY | RESULTS |
---|---|---|---|
AIR | |||
ASTM E1677 | Standard Specification for Air Barrier (AB) Material or Assemblies for Low-Rise Framed Building Walls | Air Penetration Resistance | Type 1 |
ASTM E2178 | Standard Test Method for Determining Air Leakage Rate and Calculation of Air Permeance of Building Materials | Air Penetration Resistance | .01 L/S/m2@75 Pa |
TAPPI T460 | Air resistance of paper (Gurley method) | Air Penetration Resistance | 1080 sec/100cc |
STRENGTH | |||
ASTM D882 | Standard Test Method for Tensile Properties of Thin Plastic Sheeting | Breaking Strength | 30/30 lbs/in |
TAPPI T-410 | Grammage of Paper and Paperboard (Weight per Unit Area) | Basis Weight | 1.8 oz/yd2 |
WATER | |||
ASTM E2273 | Standard Test Method for Determining the Drainage Efficiency of Exterior Insulation and Finish Systems (EIFS) Clad Wall Assemblies | Drainage Efficiency ICC-ES AC 24 Section 6.11 ICC-ES AC 235 Section 4.5 | >90% Pass Pass |
ASTM E96 | Standard Test Methods for Gravimetric Determination of Water Vapor Transmission Rate of Materials | Water Vapor Transmission Method B | 1720 ng/Pa•S•m2 30 perms |
